Underground Mining Methods of Zinc Ore

The varying physical character and large extent of the Broken Hill lode necessarily involve the employment of a variety of underground methods. The lode had its origin in an extensive fault plane traversing metamorphosed schists conformably, as a rule, with their beds of stratification. The underground waters carrying minerals in solution deposited their contents in the original cavities formed by the faulting action, and in the enlargements of these cavities due to dynamic forces brought to bear on the rocks, more especially on the hanging-wall side of the fault. This deposition was supplemented by metasomatic replacement of a portion of the original rock contents by the argentiferous sulphides of lead and zinc which form the staple products of the district.

Although the orebody is practically continuous throughout the mines, its width varies greatly, ranging from a few feet to about 350 ft. The widest portions occur in conjunction with huge folds in the enclosing country rock, almost exclusively on the hanging-wall side. The ore in these folds pitches to the south in the southern half of the field, and to the north in the northern half; there are, however, undulations in these ore channels evidently due to compression of the rocks

Underground Mining Methods of Copper

The system of stoping as practiced was eminently satisfactory to supplement the steam-shovel operations without injuring the ore reserves of the property through a mixing of capping with ore. It had the advantage that all ore produced was absolutely free from waste, since both stopes and development drifts were discontinued when capping was reached. The assay value of the ore produced could be regulated, and the tonnage materially increased or decreased without affecting to any extent the cost per ton. The mining property of the Utah Copper Co. is situated in the West Mountain mining district, Salt Lake County, Utah, in the Oquirrh Range of mountains.

Copper Geology

In a general way the rock formation of the district consists of a series of beds of quartzite and limestone intruded by a body of monzonite porphyry roughly elliptical in shape, with an east-west axis over a mile in length and a north-south axis of about 3,000 ft.

This porphyry intrusion, accompanied by strong mineralizing action and fracturing, resulted in the formation of orebodies in the adjacent sedimentary rocks, and was itself sufficiently mineralized to make it one vast orebody. The Utah Copper Co.’s mining property comprises within its boundaries practically the entire

Determination Method of Melting Points of High Fusion Temperature Metals & Alloys

In this paper, it is proposed to outline a method for the determination of melting points of those metals and alloys having high fusion temperatures. The application of the method as used to determine the melting points of alloys of tungsten and molybdenum will be given. It will be seen from these results that tungsten and molybdenum form a completely isomorphous series. This is also verified by the accompanying photomicrographs.

Tungsten and molybdenum have been found to crystallize in the same system, namely, isometric, and the crystal units are cubes. These determinations were made by examining etching pits in the pure metals.

Equipment Required

Fig. 1 shows a partial section of the apparatus used for determining the melting points of the alloys. W1 is a water-jacketed metal housing with a mercury seal m2 at the bottom, h1 is a hydrogen inlet and h2 a hydrogen outlet, c1 is the top electrode which is water-cooled, as indicated by W2. This electrode is supported by the post p, to which it is fastened by means of an adjustable sleeve. C2 is the bottom electrode which floats in a bath of mercury m1. This mercury is contained in the casting k, which is

Evaluate Metal Segregation in Gold Bullion

Several years ago the writer was connected with the Mint and Assay Service of the Federal Government as Assistant Assayer at the Salt Lake Assay Office. At that time cyanide bars formed approximately half of the bullion purchased by that office. Disagreement in valuation between the producer and the office was not infrequent and to a lesser extent between the Assay Office and the Mint, this latter issue being soon obviated, however, by adopting uniform methods of sampling the bars. A nice problem seemed to offer itself for research and the writer began a series of experiments which were soon terminated, however, by his going into other work, and which he regrets have not since been completed. The results attained may suggest lines of approach to this problem and are, therefore, offered in this article.

In the discussion of these papers, comparison has been made in terms of copper bullion, but to the writer this seems of questionable value. Copper bullion may resemble silver bullion, but its similarity to gold bullion with little or no silver content is another thing. The freezing-point diagram of Roozeboom, is for the gold-silver series as stated. The original problem under discussion, however, is

Copper Electrolytic Refining Process Explained

Experiments on a Porphyry Copper Ore: This research was done partly in the non-ferrous laboratory of the Department of Metallurgy of Columbia University, under the direction of Dr. Edward F. Kern, and completed elsewhere. Acknowledgment is due to Prof. Arthur L. Walker, Dr. Edward F. Kern and Dr. William Campbell of the Department of Metallurgy, for their kind advice and for the inspiration derived from their instruction.

This report is given under the following heads: Petrographic Description (Microscopic Study); Sampling and Preparing Ore for Treatment; Chemical Analysis; Treatment of Ore.

Mineralogy

(Minerals are grouped for interpretation purposes and are arranged in each group in approximate order of abundance)

mineralogy

The original character of the rock has been much obscured by modification. The variable texture indicates that the original rock was much brecciated. Silicification seems to have been a prominent feature. Some of the quartz appears to be remnants of primary grains. It must have been primarily an acid intrusive, which, after having been fractured and brecciated, has become still more acid by silicification. There appear to be recorded several sets of movements. The special features of most importance seem to be as follows:

Platinum Alloys with Tungsten & Molybdenum

Metallurgical research has discovered many an alloy possessing properties not combined in any single metal, and progress still consists chiefly in the investigation and utilization of alloys. In the case of iron, the demands of automobiles, high-speed machines and high-duty engines have led to the production of special iron alloys which will meet any reasonable specifications in that field. In like manner, the bronzes, brasses and other alloys of copper have been brought to remarkable perfection, and for nearly every industrial purpose some alloy has been found more suitable than the pure metal.

Less complete success has attended the attempt to find substitutes for gold, platinum, and the other precious metals. Indeed, it is not likely that a material can be produced which will possess all the properties of any one of them; yet it is reasonable to hope that, for any given use, the properties required may be found in some less expensive material. Thus, in incandescent electric lamps, the wire passing through the thick glass neck of the bulb was, until recently, almost universally made of platinum, for the single reason that no other known material, suitable as a conductor, had the same coefficient of expansion

Natural Flotation Reagents form Plants

The reagents now used in flotation consist of various acids or salts, which may be either electrolytes or nonelectrolytes, dissolved in water and some substance or combination of substances, which function as collecting or frothing agents. At times the only dissolved salts present are those naturally occurring in the water used. The general effect of the electrolyte is to greatly sharpen the separation between the gangue and the concentrate. Examples of this are: The use of sulphuric acid with zinc ores; and of sodium carbonate or calcium oxide (lime) with silver-gold ores. Crude pyroligneous acid is also sometimes used when available. Various oxidizing agents, such as permanganates, bi-chromates, etc., are added in the selective flotation of lead-zinc ores. Many other reagents for performing certain specific functions, either real or imaginary, have been proposed, and a number of them have been tried upon a working scale. The wild orgy of experimentation which is now going on in flotation exceeds even that which followed the introduction of the Washoe process for the treatment of Comstock ores, when, among other things, sagebrush tea and tobacco juice were reagents added to the pans. Out of all this will, of course, eventually come

Drill Holes Assay Result Interpretation

In the exploration of a copper deposit by drilling, obvious advantages are to be gained from a distinction between primary and secondary ore. Perhaps the chief of these is the aid which such a distinction renders in determining where a given hole should stop. The copper assay, often a sufficient guide, cannot always be exclusively relied upon. Primary ores may extend downward indefinitely and may fluctuate in value independently of depth: if primary ores are consistently lean for a considerable vertical distance, there is little reason to expect that, still deeper, they will increase to the commercial grade; on the other hand, rich primary ores may persist uninterruptedly downward or may come in again below a lean interval. Secondary ores, however, have a comparatively limited vertical extent; in a large way enrichment decreases with depth and finally gives out. It follows then, that when a hole descends from profitable ore into ore of less than the commercial minimum, the practical significance of the situation depends upon whether this decrease results from a decrease in secondary enrichment or is a variation in primary content: if the copper of the ore passed through has been chiefly secondary, little is gained in the

Lighting Underground Mine & Illumination

In preparing this paper the object has been to set forth facts relating to lighting or illumination problems faced in underground mines, which, judging from the results realized in the iron and steel and other industries somewhat similar to mining, will tend toward furthering safety, production, and contentment of employees, as well as economy of operation in mines. By applying the principles of illumination with the assistance of modern appliances, the full benefits in efficiency may be derived from improvements already made in other details of mine operation.

The lighting of a typical coal mine may be divided into four distinct parts:

  1. 1, The lighting of the buildings about the top;
  2. 2, the lighting of the working faces;
  3. 3, general illumination at the bottom; and
  4. 4, special applications of lighting.

The lighting of buildings about the top may be treated in the same manner as that of any other industrial plant, for we have a boiler room, an engine and generator room, a forge, a machine shop, and a hoist room. These can be well and efficiently lighted by the use of 100-watt tungsten-filament multiple lamps with proper reflectors so spaced and suspended that a power consumption of from ¼ watt per square

Miner’ Safety Lamps

While electric lamps both of the cap and hand type are being introduced into many mines requiring the use of safety lamps, the oil-burning safety lamp is still used in the great majority of cases, and even where the former are used the latter must continue to be employed when testing for gas. It is not the intention to discuss here the relative merits of the two types, but simply to give a comparison of the illuminating effect or candlepower of several kinds of ordinary safety lamps used for general work and for testing. Few data have been published in recent years on this subject and because of this it is hoped that the following information may be of some interest and value.

The lamps tested were in all cases of standard size and in good condition, all practically new, and were selected from a collection of about 100 with a view to obtaining results on as many different common types as possible. With the exception of the gasoline-burning lamps, five different oils were used in each lamp to determine whether particular oils were suited to particular lamps and whether there was any great difference in the illuminating power of the
